一般規(guī)格
輸出功率：1kHz，無失真，20msec爆音，所有驅動通道	16Ω	300W x 4
	8Ω	600W x 4
	4Ω	900W x 4
	2Ω	1300W x 4
	8Ω（BRIDGE模式）	1800W x 2
	4Ω（BRIDGE模式）	2600W x 2
	Hi-Z（70V 模式）	-
	Hi-Z（100V 模式）	-
功放類型		Class D, Single ended output
總諧波失真		0.01% (8Ω, 1kHz, 10W, All channels driven), 0.1% (4Ω, 1kHz, Half power, All channels driven)
頻率響應		+0.5, -1.5dB (8Ω, 1W, 35Hz to 20kHz)
串擾		≦ -60dB (8Ω, 1kHz, Half power, Input 150Ω shunt A-weighted)
信噪比		109dB (8Ω, Gain setting = 32dB, A-weighted)
電壓增益/靈敏度	8Ω音量最大	32.0dB/+7.0dBu (Gain setting: 32dB), 26.0dB/+13.0dBu (Gain setting: 26dB), 35.0dB/+4.0dBu (Gain setting: +4dBu), 25.0dB/+14.0dBu (Gain setting: +14.0dBu)
	Hi-Z 100V 模式，音量最大	-
	Hi-Z 70V 模式，音量最大	-
保護電路	荷載保護	POWER switch on/off: Output mute, Output voltage protection: Over voltage limiter, user configurable by wattage and speaker preset, DC-fault: Power supply shutdown (NOT restored automatically)
	功放保護	Thermal: Output limiter (Restored automatically) → Output mute (Restored automatically), Over current: Output mute (Restored automatically), Over voltage: Output limiter (Restored automatically), Integrated Power Limit: Output limiter (Restored automatically)
	電源保護	Thermal: Output limiter (Restored automatically) → Power supply shutdown, Over voltage: Power supply shutdown, Over current: Power supply shutdown
冷卻		7 step variable speed fan x 3, front to rear airflow
最大輸入電壓		+25dBu
輸入阻抗		20kΩ (balanced)
采樣頻率		96kHz
A/D D/A 轉換器		AD: 32-bit linear, 64 times over sampling; DA: 32-bit linear, 128 times over sampling
Dante Interface	通道計數(shù)	16 IN with Dante Redundancy, 16 OUT
	采樣頻率	96/88.2/48/44.1kHz
	Dante延遲	0.25/0.5/1/2/5ms
	位深	32/24bit
處理器		20 x 8 input matrix mixer, Room EQ: 16 band IIR EQ, Room Delay: 0 - 1000msec, Speaker Processor: X-Over (IIR/FIR), PEQ (16 band IIR/FIR), Delay, Peak Limiter, RMS Limiter
延遲		Analog Input to Speakers: 0.9msec; Dante Input to Speakers (Dante latency setup = 0.25msec): 1.5msec (fs=96kHz), 1.6msec (fs=88.2kHz), 2.0msec (fs=48kHz), 2.1msec (fs=44.1kHz)
I/O 接口	模擬輸入	XLR-3-31 x 4
	數(shù)字 I/O	Dante Interface: etherCON x 2 (Redundant/Daisy Chain)
	揚聲器輸出	Neutrik speakON NL4 x 4
	控制端口	RJ45 x 1
	AC	AC inlet (powerCON 20A) x 1
	其它	Remote, Fault Output: Euro block 8pin (mini) x2 (GPI x 4, GPO x 6, +5V x 2)
指示燈		Power (Green) x 1; Channel Status x 4 : Signal (Green), Limit (Yellow), Protect/Mute (Red); Auto LED off and dimmer feature (except POWER LED)
電源要求		100V - 240V 50Hz/60Hz **
功耗		1050W (1/8 MAX power, 2Ω, Pink noise at all channels), 165W (Idle), 100W (Sleep, all channels), 9W (Standby 100V/120V), 12W (Standby 230V)
工作溫度		0°C to +40°C
存儲溫度		-20°C to +60°C
外形尺寸	W	480mm (18.90 inch)
	H	88mm (3.46 inch): 2U
	D	528mm (20.79 inch)
凈重		15.6 kg (34.4 lbs)
附件		Owner's Manual x 1, Power Cable (2.0m) x 1, GPIO Mini Euro block plug 3.5mm 8p x 2, Air filter (L x 1, R x 1), Grill (L x 1, R x 1), Handle x 2, Screw x 4
